| Field of view | 14" x 17" plate / 36 cm x 43 cm panel |
| Spatial resolution | DR: 3072 x 2560 pixels (Vendor: Varian)
CR: 4048 x 4932 pixels (Vendor: Kodak /Care Stream Health) |
| Throughput | DR: 10 sec. cycle time (0.14 mm pixel size)
CR: 70 sec. cycle time at high resolution (0.08 mm pixel size) |
| Exposure angles | Any/Variable |
| Beam collimation | Preset or manual |
| User control | From console or through the gantry control panel |
| Processing presets | Standard (factory defaults) and user defined |
| Other features | Integrated User Interface for processing, storage and retrieval, geometric registration with CT and Fluoroscopy scenes |
| |
